HRS 12Pin Female Wire Solder Type Circular Connector IP67 Waterproof ADAMICU

The Hirose-standard 12-pin female wire-bonding industrial connector conforms to RoHS standards.
It features a zinc alloy nickel-plated/copper pearl nickel-plated shell, gold-plated 3U terminals, and PA66 silicone core. It boasts 2A/100V electrical specifications, ≤10mΩ contact resistance, over 1000 mating cycles, and a wide temperature range of -25℃ to 85℃.
Its threaded locking mechanism is suitable for high-reliability connection requirements in industrial automation, equipment signal interconnection, and other scenarios.

Inquiry

Write a Review

m16 3p 1 (2)

Hrs 12pin display2

P1096194(1)

Features

12 Pin Female Circular Connector Metal Plug for Machine Vision and Industrial Cable Assembly

Highly corrosion-resistant and robust structure: The housing is made of zinc alloy plated with nickel/copper plated with pearl nickel, featuring a threaded locking mechanism and knurled texture for vibration resistance and anti-loosening.

Excellent conductivity: Terminals are gold-plated with 3U treatment to enhance conductivity stability.

Industrial-grade stable performance: Supports 2A/100V electrical specifications, contact resistance ≤10mΩ, mating life exceeding 1000 cycles.

Can operate continuously in a wide temperature range of -25℃ to 85℃.

Pin count design: 4/6/8/10/12 Pins. .

Applications

Industrial automation equipment

Machine vision systems

Sensor and control connection

Testing and measurement instruments

Communication and signal transmission equipment

Custom industrial cable assemblies

FAQ

What is this connector mainly used for?

It is mainly used for industrial automation, machine vision, control equipment, and cable assembly projects that require a reliable Hirose-compatible circular connector solution.

Do you support cable assembly with this connector?

Yes. We not only supply the compatible connector itself, but also support matching cable assemblies according to customer requirements.

What are the main advantages of choosing your compatible replacement?

Our main advantages are more competitive pricing, stable supply, flexible customization, and support for both connector-only and cable assembly projects.

Can you provide samples for testing?

Yes. Samples are available for evaluation and compatibility testing before volume orders.

What information is needed to confirm compatibility?

To confirm compatibility, it is best to provide the original part number, technical drawing, application details, or photos of the existing connector. This helps us recommend the correct replacement model faster.

Connectors	Hrs Female Wire bonding	Classification	Circular Connector
Quantity of Pins	12pin	Spring	Stainless steel
Part number	AD-12F-001-000	Terminal material	C3604 Gold-plated 3U
Rubber core material	PA66	M2.5 screw	Iron
U-shaped wire clamp	Copper	Outer shell	Zinc alloy nickel plating, Copper-nickel pearl nickel
Rated current	2A	Rated voltage	100V
Insulation and voltage resistance	800V	Contact resistance	100mΩ
Plug/unplug cycles	>1000 times	Jacket	TPE Black
Working temperature	-25℃~85℃	Salt Spray	48h
Shielding performance	Shielding	IP rating	lP67
Flame retardant rating	UL 94-V0

Hrs 12-Pin Connector Drawing
